TK 2248 Box & Pan

Durable and dependable! The TK box and pan brakes give you all the features you would expect from quality machines. Of all steel welded construction, with adjustable truss bars and bronze bushings, these brakes are built to last. The brakes come with removable apron angle and apron insert, permitting .25″ (6.35mm) reverse bends in lighter materials. The nose bar is removable as well, and the brakes are equipped with a precise stop rod for repeat bends.

Optional stand available at a reasonable cost.

TK 2248 Box & Pan
TK 2248 Box & Pan

TK 2248 box and pan

  • Weight: 356 lbs
  • Dimensions: 64 x 28 x 32 in
  • Capacity: 22 Ga.
  • Bend Length: 48”
  • Max Beam Lift: 7/8”
  • Max Box Depth: 3”
  • Min. Reverse Bend: 5/16
  • Min. Flange: 3/8”
